EE-71 Amine Cured 100% Solids Novolac Epoxy Topcoat| Secondary Containment | Chemical Resistant | NSF 61 Potable Water | USDA | 100% Solids

Chemical Resistance

1. Excellent: Suitable for Immersion 2. Very Good: Suitable for Immersion 3. Good: Suitable for Secondary Containment 4. Fair: Spill/Splash

Alkalies

Solvents

ACIDS

Product Use Instructions

SURFACE PREPARATION

Steel surfaces are to be abrasive blasted with chloride free abrasive. Exterior applications to SSPC SP-10 Near White metal finish. Immersion applications to SSPC SP-5 White metal 3 to 5 mil profile. Grind flat all burrs, weld seams, radius sharp edges. Fresh blasted ferrous surfaces to be primed immediately with S-30 Prime or EE-71 to prevent oxidation of surface.

Concrete surfaces should be degreased if oil and grease contamination is present. Degreased surface shall be high pressure washed. Loose existing coatings should be chipped & ground to remove the entire floor is to be abrasive blasted to remove all existing coatings, Prime entire floor with EE-10, EE-71.

MIXING:

Thoroughly mix Activator into Base with mixing stick or drill with low speed mixing blade scraping sides and bottom of container or mixing board. Mix by Volume 2 parts Base to 1 part Activator. Or by weight 100 grams base to 34 grams activator. Mix thoroughly to produce an even colored and streak-free material.

THINNING: Never Thin

APPLICATION:

Squeegee: heavy duty rubber ‘notched’ squeegee

Roller: good quality 1″ nap

Plural Spray: .017-.025 tip, 3,000-3,500 PSI, Heat to 110ºF Base, 100ºF Activator

Airless Spray: 019-.027 tip, 3,000-3,500 PSI(45:1). (Caution: Short Pot-Life)

Conventional Spray: Not Recommended

All spray equipment should employ traps to prevent water and oil from contaminating coating and screens to prevent particulate contamination.

APPLICATION TEMPERATURE:

Material: Keep between 55 to 95F. Substrate: Keep between 45 to 105F. The difference in temperature of the substrate and the material should never exceed 10F. Substrate shall be a minimum of 5F above dew point. Do not apply if relative humidity exceeds 90%. If necessary, heat metal prior to surface preparation using electric heater or heat lamp. Never use gas, oil or kerosene heaters as they will leave a greasy residue on metal surface. For best results, keep all material in warm area overnight (75F+) for ease of mixing. If necessary base component of material can be heated by microwave for 30-45 seconds for a 1KG Base unit or by warm water bath. Heat activator by warm water bath only. If necessary let material cool before application.

OVERCOAT/CURE TIME:

By brush, roller or squeegee recoat while material is still soft,  but tack-free, between 6-14 hours at 77F. If overcoat window is exceeded abrade surface with course sandpaper, grinder or brush blast. By spray application recoat between 2-14 hours at 77F. Full cure before immersion 72 hours at 77F. Add 30 hours additional cure time for each 10F below 77F. Subtract 12 hours of cure time for each 10F above 77F. Force Cure with heat for best performance for 4 hours at 200F, 12 hours at 150F.

CLEAN UP:

Clean tools immediately after use with MEK , Acetone or similar. Isoproply Alcohol can be used in solvent restricted areas.

WARNING: Base contains epoxy resin. Activator contains alkaline amines, a strong sensitizer. May cause skin irritation, sensitization or other allergic responses. Use with
good ventilation, particularly if heated or sprayed. Prevent all contact with skin or eyes. Wear protective clothing, goggles, gloves or barrier creams. Keep containers closed
when not in use. Wash thoroughly after handling. In case of skin contact immediately wash with soap and water. In case of eye contact, flush with water for 15 minutes. If irritation persists seek medical attention.

Manufacturer, Novolac Epoxy Technologies Inc., makes no warranty either expressed or implied including warranties of merchantability or fitness for a particular purpose for this product. Under no circumstances will the manufacturer be liable for incidental, consequential or other damages, breach of warranty, strict liability, or any other theory arising out of use of this product. The information and or recommendations contained herein are based on standard Product and are proprietary and furnished solely for the use of our customers. This information is provided in good faith and believed to be true and accurate as of the date/version of this document. As the manufacturer has no control over the use conditions or application process of the parties using this product, the manufacturer cannot accept responsibility for loss, injury or other damages resulting from the use of the Product or this or any other information provided by the manufacturer. Therefore, no guarantees of any kind, expressed or implied, are made by the manufacturer, Novolac Epoxy Technologies Inc., regarding this, or any, product manufactured by them or any contracted or licensed manufacturer. ARCOR® epoxy products do not provide structural integrity or improvement. They are only used to provide protection from corrosion, wear, abrasion and chemical attack on a given substrate and only to the extent provided for in the Data Sheets, Technical Data Sheets, Safety Data Sheets and any other information as supplied in writing directly from manufacturers technical support.
