E1900 Polyaspartic Clear | 40-50 Min Work Time | High Solids | Apply 40°F – 100°F | Chemical Abrasion Impact Resistant

E1900 is a two component clear high solids polyaspartic high performance floor coating for residential, commercial and industrial projects. E1900 produces a tough, durable clear non-yellowing film with excellent chemical, abrasion and impact resistance.

The E1900 is designed as a high performance, fast curing topcoat for flake and quartz granule floors as well as solid color coating systems.  Meets FDA requirements for incidental food contact and great for use in food plants and commercial kitchens.

Easy to use 1:1 mix formula, the E1900 is ideal for use as a clear topcoat in both interior and exterior Industrial and Commercial applications.  Not for use directly on unprimed surfaces and not designed for submerged service.   Can be applied to existing epoxy, polyaspartic or urethane coatings (do not apply to acrylic paint) after proper preparation including sanding and wiping with acetone solvent right before application (apply E1900 as soon as acetone solvent is dry).

Available in 2 gallon kit and 10 gallon kits (requires 1 week lead time) with mix ratio 1:1 by volume (1 part Base Part A to 1 part Hardener Part B).  Long 40-50 min working time @ 75ºF.

Apply at 3-12 dry mils per coat depending on system requirements.  As thick as 110 sq’/gallon (12 mils DFT – dry film thickness) for full flake and quartz granule systems to as thin as 420 sq’/gallon (3 mils DFT) topcoat over smooth pigmented epoxy surfaces.  Typical flake systems range from 110 to 200 sq’/gallon and when applied over solid color smooth coatings typically 250 to 400 sq’/gallon.

Application using a short nap roller 1/4″ or 3/8″ or brush.

BASECOAT: Recommend the E707HB Epoxy available in 20 colors or the 6009 Epoxy for low temperatures down to 35FDo not apply direct to concrete.  Can be applied to existing coatings after proper preparation including sanding using 100 grit and wiping with acetone solvent right before application (apply E1900 as soon as acetone solvent is dry – not for application to acrylic coatings).

TOPCOAT:  Can apply multiple coats of the E1900 Clear

Where is the E1900 Polyaspartic Clear used?

  • Garage floors
  • Basement floors
  • Warehouse floors
  • Production floor areas
  • Aircraft hanger floors
  • Factories
  • Schools
  • Hospitals
  • Nursing & retirement homes
  • Jails
  • Cafeterias
  • Dormitories
  • Rest rooms
  • Locker rooms
  • Showers
  • Kitchens
  • Laundry rooms
  • Laboratories
  • Medical & veterinary clinics
  • Commercial Lobbies, entrance & walkways
  • Offices
  • Waiting rooms
  • Cleaning rooms
  • Restaurants
  • Shopping centers
  • Supermarkets

Why E1900 Polyaspartic Clear Coating?

  • Excellent Clear Top coat for decorative flake and quartz granule systems and solid color epoxy coatings.
  • Fast set
  • Resistant to hot tire pick up.
  • Highly resistant to chemical, abrasion and impact
  • Meets USDA requirements for incidental food contact
  • High Gloss
  • Extremely hard, yet flexible.
  • Excellent weather resistance
  • Outstanding “wearing” properties.
  • Easy to clean.
  • Non-chalking and non-yellowing
  • Apply up to 12 mils DFT in one coat (110 sq’/gallon)

SPECIFICATIONS

Solids By Volume Clear 80% +/- 3%
VOC Clear 182 g/L
Colors Clear
Recommended Film Thickness 3 – 12 mils per coat at 110-420 sq’/gallon
Shelf Life 12 months minimum in unopened container
Packaging 2 gallon kit, 10 gallon kits (7 day lead time)
Mixing ratio 1:1 by volume.  Mix 1 parts Base (Part A) to 1 part Hardener (Part B)
Working Time @ 75°F: 50% R.H. 40-50 minutes
Gloss Level High Gloss:   60º GLOSS: 90 ± 5%
Abrasion Resistant CS-17 Wheel, 1000 cycles, 1 kg load:  34 mg ASTM D4060
Dry Heat Resistance  190ºF ASTM D2485
Bond Strength 340 PSI (concrete fails) ACI 403
Impact Resistance Passes Direct 120 inch lbs ASTM D2794
Flexibility Passes 180º Bend 1/8″ mandrel ASTM D522
Pencil Hardness Gauge Method 2H  ASTM D3363
Sward Hardness Result 68  ASTM D2134
Clean up Xylene or MEK
Induction time None
Thinning None

COVERAGE RATE

Coverage Rate 3 – 12 mils per coat at 110-420 sq’/gallon

CURE SCHEDULE

Temperature Min Recoat Max Recoat Foot Traffic Heavy/Vehicular Traffic
90ºF 4 hours 6 hours 7-8 hours 24 hours
75ºF 8 hours 12 hours  10-12 hours 48 hours
50ºF 10 hours 16 hours 12-16 hours 72 hours

APPLICATION TEMPERATURE: 40ºF – 100ºF Do not apply to surfaces below 40°F or above 100°F. Relative humidity should not exceed 85%.  Do not apply over dew or frost. The surface temperature should be at least 5°F above the dew point.

CHEMICAL RESISTANCE, SPLASH and SPILL TESTING

Not recommended for Immersion Conditions.

Antifreeze Glucose Orange Juice
Barium Sulfate Grape Juice Peanut Oil
Beer Glycerin Potassium Hydroxide
Brake Fluid Hydraulic Fluid Power Steering Fluid
Brine Jet Fuel, JP-4, JP-5 Rum
Citric Acid Kerosene Sea Water
Corn Oil Ketchup
Cutting Oils Lactic Acid 10% Sodium Hydroxide 20%
Crude Oil Lard Soybean Oil
Diesel Fuel Linseed Oil Sulfuric Acid 10%
Distilled Water Tannic Acid
Ethylene Oxide Milk Vegetable Oil
Ethylene Gylcol Mineral Oil Vodka
Fuel Oil Mineral Spirits Wine
Gasoline, Avaiation Molasses Whiskey
Gasoline, Regular Motor Oil
Gasoline, Premium Olive Oil

MIXING AND APPLICATION INSTRUCTIONS

SURFACE PREPARATION

In all cases of surface preparation, the pH should be checked.  A pH reading of 7.0 to 8.5 is acceptable.  Also, a Water

Dissipation Test should be made on random areas of the floor to determine if the proper degree of porosity Has been achieved.  Before the installation of any Gulf Coast Paint products, the substrate should be examined for moisture. Test Test for moisture vapor transmission using ASTM F-1869 Standard Test Method for Measuring Moisture Vapor Emission Rate of Concrete Subfloor using Anhydrous Calcium Chloride.  The maximum allowable rate is 3 lbs. per 1000 square feet per 24 hours.  Test for relative humidity in concrete floor slabs using Probes according to ASTM F-2170.  This test mea-sures the presence relative humidity of the slab below the surface.  The maximum relative humidity should be below 80%.

New concrete must be cured at least a minimum of 28 days before applying a coating.  On-grade slabs must have moisture vapor barrier in place.  All laitance, sealers, efflorescence, chemical contaminants, grease, oil and other foreign matter must be removed.  The prepared surface must be clean, dry and structurally sound.  Recommend mechanical preparation by means of shot blasting or diamond grinding to achieve a CSP-2 OR CSP-3 profile, in accordance with the International Concrete Repair Institute (ICRI).  The profile should reflect something similar to a 60-100 grit sandpaper.  If the substrate is not properly prepared and the appropriate profile is not achieved, failure of the product to adhere to the substrate may occur.

Apply over appropriate primers or intermediate coats.  Not designed to be applied directly to concrete.

MIXING INSTRUCTIONS

Stir each component to a uniform consistency. Do not vary proportions. PC-1900 is prepared by mixing 1 part BASE (Part A) to 1 part HARDENER (Part B) with a slow speed explosion proof variable speed drill with a Jiffy mixer. Be sure material is thoroughly mixed together. Do not thin E1900. Use as supplied.

For best mixing results and proper blending of parts A and B, recommend a Jiffy Mixer style drill mixer.

Use of an improper drill mixer can result in curing problems if the hardener also called activator (Part B) is not thoroughly blended with the resin (Part A) which can cause some areas on your floor to remain soft and not harden properly.  DO NOT USE A PAINT MIXER.  Most mixing problems described above can be traced back to using a paint mixer..  DO NOT HAND MIX as this approach can result in the same problems as using a paint mixer.

NOTE:  Always wear protective gloves and clothing while mixing and applying E352P.  Do not get on skin.

APPLICATION PROCEDURE

Best method of application is conventional or airless spray use up to 10% Thinner.  Flush equipment thoroughly with MEK solvent before using and use a moisture trap on the air supply.

Surfaces must be free from all oil, grease, water or other foreign matter.  Surface should be dry and above 50°F and rising.  Relative humidity should not exceed 85%.  CT-352 is moisture sensitive during application and initial cure.  Do not apply if surface temperature is within 5° of Dew Point.  Not recommended on floors, susceptible to hydrostatic pressure.   For safety and proper curing, proper ventilation is necessary throughout application and cure.  Any foodstuff and furnishings in the application area should be removed prior to application.  When using pigmented Intermediate Coats, be sure the batch numbers are all the same to provide a uniform color.

E1900 Clear polyaspartic coating is a top coat and is normally not recommended directly over unprimed surfaces. Apply over appropriate primers, intermediate coats, or decorative floors. Surfaces must be free from all oil, grease, water or other foreign matter. Surface should be dry and above 40°F. Relative humidity should not exceed 85%. E1900 is moisture sensitive during application and initial cure. Do not apply if surface temperature is within 5° of Dew Point. Not recommended on floors susceptible to hydrostatic pressure.

Best method of application is to pour material on the floor in a ribbon and spread with a flat blade squeegee.  Immediately backroll spread material with 18 inch roller, 1/4”–3/8” nap.  Maintain a wet edge. Do not over roll and entrap air.

Coverage over flake is typically 110-200 square feet per gallon and coverage over a smooth coating is typically 250-400 square feet per gallon.  For safety and proper curing, proper ventilation is necessary throughout application and cure. When using pigmented Intermediate Coats, be sure the batch numbers are all the same to provide a uniform base color.

Do not apply to surfaces below 50°F or above 100°F.   Do not apply over dew or frost.  The surface temperature should be at least 5°F above the dew point.  Relative humidity should not exceed 85%.

CAUTION DANGER

E1900 is flammable.  Keep away from all sources of ignition during mixing, application and cure.  The use of goggles, fresh air masks or NIOSH approved respirators, protective skin cream and protective clothing is a recommended standard practice when spraying.  This product is sold without warranty as to performance expressed or implied.  Users are urged to make their own tests to determine the suitability for their particular conditions.

LIMITATIONS:

  • Do not apply over frost surfaces or extremely high humidity conditions.
  • Do not apply over expansion joints.
  • Do not apply if the surface temperature is within 5° of the dew point.
  • Partially used containers must be reclosed tightly to prevent moisture in air from reacting with material and forming a tough skin.  Skin can be removed and remaining material used.  Be sure to stir.

SEE MATERIAL SAFETY DATA SHEET FOR FULL SAFETY PRECAUTIONS.  FOR PROFESSIONAL AND INDUSTRIAL USE ONLY  KEEP AWAY FROM CHILDREN.  NOT FOR RESIDENTIAL USE NOTICE TO BUYER: DISCLAIMER OF WARRANTIES AND LIMITATIONS ON OUR LIABILITY We warrant that our products are manufactured to strict quality assurance specifications and that the information supplied by us is accurate to the best of our knowledge. Such information supplied about our products is not a representation or a warranty. It is supplied on the condition that you shall make your own tests to determine the suitability of our product for your particular purpose. Any use or application other than recommended herein is the sole responsibility of the user. Listed physical properties are typical and should not be construed as specifications. NO WARRANTY IS MADE, EXPRESSED OR IMPLIED, REGARDING SUCH OTHER INFORMATION, THE DATA ON WHICH IT IS BASED, OR THE RESULTS YOU WILL OBTAIN FROM ITS USE. N0 WARRANTY IS MADE, EXPRESSED OR IMPLIED, THAT OUR PRODUCT SHALL BE MERCHANTABLE OR THAT OUR PRODUCT SHALL BE FIT FOR ANY PARTICULAR PURPOSE. NO WARRANTY IS MADE THAT THE USE OF SUCH INFORMATION OR OUR PRODUCT WILL NOT INFRINGE UPON ANY PATENT. We shall have no liability for incidental or consequential damages, direct or indirect. Our liability is limited to the net selling price of our product or the replacement of our product, at our option. Acceptance of delivery of our product means that you have accepted the terms of this warranty whether or not purchase orders or other documents state terms that vary from this warranty. No representative is authorized to make any representation or warranty or assume any other liability on our behalf with any sale of our products. Our products contain chemicals that may CAUSE SERIOUS PHYSICAL INJURY. BEFORE USING, READ THE SAFETY DATA SHEET AND FOLLOW THE PRECAUTIONS TO PREVENT BODILY HARM.
