H20 zioTHANE Low Gloss Urethane Concrete Sealer

H2O zioTHANE Low Gloss Urethane Concrete Sealer/Topcoat is a two component, water-based, aliphatic high performance, low gloss urethane sealer for concrete floors and topcoat to epoxy floor systems. H2O zioTHANE offers excellent abrasion and exceptional impact resistance, very good chemical resistance, and UV stability, with no objectionable solvent odors associated with other urethanes.

H20 zioTHANE is sold in 30 oz trial size kits, 3 gallon and 15 gallon kits. It is available in clear only.

PRIMER: Recommended as topcoat to high performance epoxy systems

TOPCOAT: None recommended.  Can apply multiple coats of H20 Hyperthane

 Where is H20 zioTHANE Low Gloss Urethane used?

  • Concrete floors
  • Chemical exposure areas
  • Auto facilities
  • Aircraft hangers
  • Warehouse and commercial office floors
  • Garages
  • Kitchens

Why H20 zioTHANE Low Gloss Urethane?

  • Tough, durable topcoat for epoxy floor coatings
  • Excellent chemical and abrasion resistance
  • Exceptional impact resistance
  • Aliphatic, UV Stable and will not yellow
  • Beautiful clear, low gloss appearance
  • Designed for high traffic and industrial areas
  • Water based, Low voc <10 g/L

SPECIFICATIONS

Solids By Weight 60%   By Volume 55%
VOC  <10 g/L
Colors  Clear only
Recommended Film Thickness  4 – 5 mils wet
Coverage per Gallon  300-350 sq’/gal
Packaging 3 gallon kit, 15 gallon kit
Mix Ratio 2:1 by volume (3 gal kit = 2 gal part A & 1 gal part B)
Self Life 6 months in unopened container
Finish Low gloss <20 at 60 degrees
Abrasion Resistance Taber abrasion CS-17 calibrase wheel with 1000g total load & 500 cycles= 23.0 mg loss
Viscosity Mixed 500-650 centipose typical
Flexibility No cracks on 1/8″ mandrel
Adhesion >320 psi @elcometer (concrete failure, no delamination, over primer/coating)
Impact Resistance Gardner impact, direct = 161 in lb (passed)
Application Temps 55F – 95F

COVERAGE RATE

Coverage Per Gallon  300-350 Sq’/Gal



CURE SCHEDULE

Pot Life 1 hours
Tack free (dry to touch) 5-7 hours
Recoat or topcoat 7-12 hours
Light foot traffic 24 hours
Full cure (heavy traffic) 3-5 Days

APPLICATION TEMPERATURE: 30-90 degrees F with relative humidity below 90%

CHEMICAL RESISTANCE

RATING
 Acetic acid 5% C
 Xylene D
 Mek B
 Ethylene alcohol D
10% sodium hydroxide E
 10% sodium hydroxide D
10% sulfuric Acid D
 10% Hydrochloric Acid D
20% Nitric Acid C

Rating key: A – not recommended, B – 2 hour term splash spill, C – 8 hour term splash spill, D – 72 hour immersion, E – long term immersion.

MIXING AND APPLICATION INSTRUCTIONS

PRODUCT STORAGE: Product must be stored in an area that will bring the product to room temperature prior to using. Continuous storage should be between 60 and 90 degree F. Keep from freezing

SURFACE PREPARATION: Preparation methods may vary depending on the system being applied. When installing a one or two coat thin build system (3-10 mils dry) mechanical scarification until a suitable profile is achieved is recommended. Floor systems that are higher than 10 mils dry, a fine brush blast (shot blast), is recommended. To assure a trouble free bond, all dust, oil, dirt, foreign contaminants and laitance must be removed. It is recommended to perform a moisture test to determine that the concrete has an appropriate vapor barrier. This can be done by placing a 4’X4’ plastic sheet on the substrate and taping down the edges. Once 24 hours has passed, and the substrate is still dry below the plastic sheet, then the substrate does not show signs of eventual hydrostatic pressure problems that may later cause disbonding. This test does not guarantee, however, that there may not be future hydrostatic pressure issues in the future.

PRODUCT MIXING: Kits should be mixed in their entirety. Pre-mix both Part A and Part B before making any batches. If partial kits are to be used, the product mixing ratio is 2 parts A to 1 part B. After the two parts are combined, mix well with slow speed mixing equipment until the material is thoroughly mixed and streak free, avoid whipping air into the product when mixing. Improper mixing may result in product failure. For best mixing results and proper blending of parts A and B, recommend a Jiffy Mixer style drill mixer.

Use of an improper drill mixer can result in curing problems if the hardener also called activator (Part B) is not thoroughly blended with the resin (Part A) which can cause some areas on your floor to remain soft and not harden properly.  DO NOT USE A PAINT MIXER.  Most mixing problems described above can be traced back to using a paint mixer..  DO NOT HAND MIX as this approach can result in the same problems as using a paint mixer.

PRODUCT APPLICATION: Use a brush or 3/8” nap roller to apply the mixed material. Maintain temperatures within the recommended ranges during the application and curing process. Properly prime the substrate. It is best to maintain a wet edge to avoid roller marks. Roller marks cans also occur if the product is put down too thin, or if over rolled. The easiest way to install this product is, after mixing it, pour the product into a flower watering container, then pour the product onto the floor as evenly as possible. Do not pour it all out onto the floor, only pour out in small sections. Once you pour out the first section, begin rolling it out evenly, the spread rate is 300-350 sq.ft. per gallon. Do not over roll or cross hatch, it’s not necessary, and will cause roller marks. When you are near the end of the first section, then take the watering container and begin pouring out a new section, pouring directly into the ribbon that remained. Continue this process until the entire floor has been rolled out. Direct sunlight or high temperatures may cause visible roller making during application. Applying the product too thin and over rolling the product, may result in roller marks in the floor. Avoid applying uneven thicknesses, this may cause variations in gloss. The pot life may seem to be longer, however, it is not recommended to apply product beyond one hour of it being mixed. After the product is mixed, the air exposure may cause skimming on the top of the product if container is left uncovered. Simply remove the thin layer, and re-mix product and apply. After an extended period of time, any product not used, may foam up and expand.

RECOAT OR TOPCOATING:Installing multiple coats of this product is acceptable. If recoating this product, be sure that all of the volatile compounds have evaporated from the coating during the curing process. Refer to the cure schedule as a guideline to follow, however it is best to test the coating before recoating or topcoating. Pressing your thumb on the coating to ensure a fingerprint impression is not visible, is a good way to determine if ready to recoat. If there is no impression visible, then coating the floor can be done. Note, colder temperatures require longer cure times before product can be recoated. Prior to coating the floor, make sure there are no contaminants exist. If contaminants or a blush exists, remove with a standard detergent cleaner and ensure floor is clean and dry prior to coating. When recoating this product with subsequent coats of urethane, make sure to apply the recoat within the 24 hour time frame. It is recommended to degloss the previous floor prior to coating to ensure a trouble free bond.

CLEANUP/FLOOR CLEANING:Use PM solvents for cleanup. When cleaning the floor, CAUTION! Some cleaners may affect the color of the installed floor. Test each cleaner used in a small area, ensuring no damage occurs. Restrict the use of the floor to light traffic and non-harsh chemicals until the floor is fully cured, refer to the cure schedule. Allow the floor to remain completely dry during the curing process.

RESTRICTIONS: Restrict the use of the floor to light traffic and non-harsh chemicals until the coating is fully cured (see technical data under full cure). It is best to let the floor remain dry for the full cure cycle. Dependent on actual complete system application, surface may be slippery, especially when wet or contaminated; keep surface clean and dry.

LIMITATIONS:

  • Colors or gloss may be affected by high humidity, low temperatures, chemical exposure, or exposure to lighting such as sodium vapor lights.
  • Installing product too thick may result in surface imperfections, bubbles, or product failure
  • Do not expose this product to water until fully cured
  • Substrate temperature must be 5°F above dew point
  • All new concrete must be cured for at least 30 days
  • Physical properties are typical values and not specifications
  • Light or bright colors (white, safety yellow, etc. may require multiple coats or a suitable color coordinated primer to achieve a satisfactory hide
  • Always apply a test patch to determine product suitability and adhesion performance for your proposed application method and procedures
  • Colors may vary from batch to batch, therefore use only product from the same batch for an entire job
  • Physical properties listed on this technical data sheet are typical values and not specifications.

NOTICE TO BUYER: DISCLAIMER OF WARRANTIES AND LIMITATIONS ON OUR LIABILITYFloorguard Products® warrants that our products are manufactured to strict quality assurance specifications and that the information supplied by us is accurate to the best of our knowledge. Such information supplied about our products is not a representation or a warranty. It is supplied on the condition that you shall make your own tests to determine suitability of our product for your particular purpose. Listed physical properties are typical and should not be construed as specifications. NO WARRANTY IS MADE, EXPRESSED OR IMPLIED, REGARDING SUCH OTHER IFNORMATION, THE DATA ON WHICH IT IS BASED, OR THE RESULTS YOU WILL OBTAIN FROM ITS USE. NO WARRANTY IS MADE, EXPRESSED OR IMPLIED, THAT OUR PRODUCT SHALL BE MERCHANTABLE OR THAT OUR PRODUCT SHALL BE FIT FOR ANY PARTICULAR PURPOSE. NO WARRANTY IS MADE THAT THE USE OF SUCH INFORMATION OR OUR PRODUCT WILL NOT INFRINGE UPON ANY PATENT. We shall have no liability for incidental or consequential damages, direct or indirect. Our liability is limited to the net selling price of our product or the replacement of our product, at our option. Acceptance of delivery of our product means that you have accepted the terms of this warranty whether or not purchase orders or other documents state terms that vary from this warranty. No representative is authorized to make any representation or warranty or assume any other liability on our behalf with any sale of our products. Our products contain chemicals that may CAUSE SERIOUS PHYSICAL INJURY. BEFORE USING, READ THE MATERIAL SAFETY DATA SHEET AND FOLLOW ALL PRECAUTIONS TO PREVENT BODILY HARM.
