E1500HN Novolac Epoxy | Superior Steel & Concrete Chemical Horizontal Protection | Secondary Containment

E1500HN is a 100% solids, two component Epoxy Novolac resin designed for concrete restoration and protection in extremely chemical corrosive environments.  E1500HN resin and curing mechanism are based on advanced polymer chemistry, providing the highest chemical resistance of epoxies available today.

E1500N has excellent chemical resistance to many acids, caustics, salts, aromatic and aliphatic solvents.  Designed for use in splash, spillage of aggressive chemicals including 98% Sulfuric Acid and 37% HCL.

Great for secondary containment for wide range of chemicals when chemical contact temperatures below 150°F and used with  E15M Epoxy Mastic Primer as part of a specified system (contact us with chemical exposure requirements for system details at sales@exteriorcoatings.com).

For primary chemical containment and vertical service protection requirements see E555VN Novolac Epoxy.

Recommended as a resin for restoration of concrete floors, sumps, drainage ditches, loading docks, tanks, ramps, storage silos, pump pads, and other concrete structures subjected to extreme chemical attack.  E1500N can be used as a resin with fiber glass reinforced systems.  E1500N is used as a coating in “seed-in” systems and also used as a “neat” coating.

Available in a 1 gallon kit and Dark Gray color.  May be applied in cold, damp conditions to 45°F with curing down to 35°F

PRIMER:  Recommend as needed  E15m Epoxy Mastic Primer

TOPCOAT: Not typically required but can apply a 2nd coat.

Where is the E1500HN Novolac Epoxy used?

  • Chemical processing plants
  • Battery Charging Stations
  • Pulp and Paper Mills
  • Sewage and waste water treatment facilities
  • Fertilizer plants
  • Petroleum refineries
  • Electric generating stations
  • Coal handling operations
  • Food Processing
  • Manufacturing plants
  • Warehouses

Why E1500HN Epoxy?

  • Excellent resistance to acids, alkalis, salts, most industrial chemicals and many solvents
  • For Use in tough corrosive chemical environments including 98% Sulfuric Acid, 37% HCL and 70% Sodium Hydroxide
  • Great horizontal chemical protection for Secondary Containment for both steel and concrete surfaces
  • Thin film self leveling to 40 mils DFT one coat
  • Extremely tough with high wearing properties
  • Excellent abrasion resistance and impact resistance
  • Meets USDA requirements

SPECIFICATIONS

Solids By Volume 100%
VOC 7 g/L
Finish High Gloss
Recommended Coverage & Dry Film Thickness 16-40 mils DFT or 40-100 sq’/gallon
Coverage per Gallon 40-100 sq. ft. per gallon
Packaging 1.5 gallon kit
Mixing ratio 2:1 by volume.  Mix 2 parts Base (Part A) to 1 part Hardener (Part B)
Shelf Life 12 months in unopened container
Compressive Strength 12,000 – 14,000 psi ASTM C109-49
Shore Hardness  85 per ASTM D2240
Tensile Strength 8,000 psi ASTM D638-60
Flexural Strength  4,000 psi ASTM D790
Bond Strength  350 psi fails per ACI test #59-43
Tensile Elongation  2.3% ASTM638
Colors Clear, Dark Gray, Brick Red
Dry Service Temperature 250°F
Recoat time @ 75°F 4 hours minimum; 24 hours maximum
Application roller, squeegee, seed in or trowel
Application temperature 55°F to 100°F
Thinner do not thin

COVERAGE RATE

Coverage Per Gallon 40-100 Sq. Ft. Per Gallon

CURE SCHEDULE

BACK IN-SERVICE TIMES AT75°F.

Highly Filled Mortars Self Leveling Slurries Dry Sealer
Working Time 15-20 min 15-20 min 15-20 min
Foot traffic 4-5 hours 6-8 hours 8-12 hours
Forklift traffic 24-48 hours 24-48 hours 24-48 hours

APPLICATION TEMPERATURE:  55°-100°F with relative humidity below 90%.

CHEMICAL RESISTANCE, SPLASH & SPILLAGE (spill time for 72 hours contact with surface) Testing at 75°F

Acetic Acid 56% (45 days) Lactic Acid
Acrylic Acid Ethyl Acetate Propionic Acid
Aluminum Chloride 29% Ethylene Dichloride (7 days) Propylene Gylcol Monomethyl Ether
Aluminum Nitrate 50% Ethylene Glycol Propylene Glycol Monomethyl Ether Acetate
Aluminum Sulfate 49% Ethylene Oxide Psuedocumene
Ammonium Chloride Ethylene Glycol Monopropyl Ether Skydrol 500B
Ammonium Hyroxide 28% Gasoline Unleaded Premium Sodium Hydroxide 70%
Ammonium Nitrate Glucose Sodium Hypochlorite 10%
Ammonium Sulfate Glycerine Sour Crude Oil
Ammonium Sulfide 25% Glycol Ether EB Sulfuric Acid 93%-98%
Glyoxal 40% Heptane Sweet Crude Oil
Beer Hexane Tannic Acid
Black liquor Hexylene Glycol Tataric Acid
Benzyl Alcohol Hydrochloric Acid 37% Toulene
Butyl Alcohol Hydrofluic Acid 5% Tomato Juice
Brake Fluid Hydraulic Fuid Transmission Fluid
Brine Hydrogen Peroxide 5% I,I,I Trichloroethane
Butanol (normal) Hydrogen Sulfide Trichloroethylene
Calcium Chloride Iodine Vinegar (White)
Calcium Hypochlorite 10% Isobutyl Alcohol
Calcium Nitrate Isopropyl Alcohol Vinyl Toluene
Carbon Dioxide (wet) JP-4, 5, 7 Jet Fuel Xylene
Carbon Tetrachloride Kerosene Zinc Chloride
Chromic Acid 20% Magnesium Hydroxide Zinc Nitrate
Citric Acid 50% Mineral Spirits
Cumene Mineral Oil
Cyclohexenone MTBE
Diacetone Alcohol Naptha (VMP)
Diesel Fuel Nitric Acid
Diethylene Glycol Oleic Acid
Distilled Water Para-Xylene
Ethanol Perchlorethylene
Ethyl 3-Ethoxypropionate Phosphoric Acid 85%
Ketchup Power Steering Fluid

MIXING AND APPLICATION INSTRUCTIONS

SURFACE PREPARATION

In all cases of surface preparation, the pH should be checked. A pH reading of 7.0 to 8.5 is acceptable.  Also, a Water Dissipation Test should be made on random areas of the floor to determine if the proper degree of porosity has been achieved. Before the installation, the substrate should be examined for moisture. Test for moisture vapor transmission using ASTM F-1869 Standard Test Method for Measuring Moisture Vapor Emission Rate of Concrete Subfloor using Anhydrous Calcium Chloride. The maximum allowable rate is 3 lbs. per 1,000 square feet per 24 hours. Test for relative humidity in concrete floor slabs using Probes according to ASTM F-2170. This test measures the presence relative humidity of the slab below the surface. The maximum relative humidity should be below 80%.

New concrete must be cured at least a minimum of 28 days before applying a coating. On-grade slabs must have moisture vapor barrier in place. All laitance, sealers, efflorescence, chemical contaminants, grease, oil and other foreign material must be removed.

The prepared surface must be clean, dry and structurally sound.   Recommend mechanical preparation by means of shot blasting or diamond grinding to achieve a CSP-2 or CSP-3 profile, in accordance with the International Concrete Repair Institute (ICRI). The profile should reflect something similar to a 60-100 grit sandpaper. If the substrate is not properly prepared and the appropriate profile is not achieved, failure of the product to adhere to the substrate may occur.

Old concrete surfaces must be structurally sound. Any unsound areas must be repaired prior to proceeding with the resinous installation. For proper patching and repairing, use CF-615 and/or E1000 with graded aggregate.  Remove existing paint and loose concrete by rough sanding, sandblasting, high pressure water cleaning, shot blasting or grinding. In some cases where plant conditions allow, a  stripper may be used to remove excessive build-up of paints or sealers.

APPLICATION PROCEDURE

E1500HN must be applied over the PC-155 or PC-1703 while they have a slight tack. PC-1500 can be applied as an aggregate filled epoxy mortar by hand trowel. Apply pressure to compact material to a dense, monolithic topping. E1500HN can be squeegeed for self-leveling, thin film coating and reinforced floors. E1500N is also used as a 16-40 mil coating. A porcupine roller is recommended to break any air bubbles in the E1500N when rolling.

For exterior use or higher film build, seed dry E1500N with fine aggregate. For vertical coating requirements, recommend the E555VN Novalac Epoxy.

CURE TIME

The aggregate filled epoxy mortar has an open time of approximately 15-20 minutes at 75°F. Immediately after mixing a batch it should be placed and spread onto the surface to be protected. Highly filled, will be ready for foot traffic in 4-5 hours. Self-leveling slurries will be ready for foot traffic in 6-8 hours and fork lift traffic in 24 – 48 hours. In aggressive areas, a 16-40 mil dry sealer coat of E1500HN is recommended to top coat mortars and self leveling slurries. A 16-40 mil coat will be ready for foot traffic in 8-12 hours.



CAUTIONS

E1500HN Novolac Epoxy is Flammable.  Keep away from all sources of ignition during mixing, application and cure.  The Hardener and Base can cause eye and skin burns as well as allergic reactions.  Use goggles, fresh air masks or NIOSH approved respirators, protective skin cream and protective clothing. This product is sold without warranty as to performance expressed or implied.  Users are urged to make their own tests to determine the suitability for their particular conditions.

SEE MATERIAL SAFETY DATA SHEET FOR FULL SAFETY PRECAUTIONS.  FOR PROFESSIONAL AND INDUSTRIAL USE ONLY  KEEP AWAY FROM CHILDREN.  NOT FOR RESIDENTIAL USE NOTICE TO BUYER: DISCLAIMER OF WARRANTIES AND LIMITATIONS ON OUR LIABILITY We warrant that our products are manufactured to strict quality assurance specifications and that the information supplied by us is accurate to the best of our knowledge. Such information supplied about our products is not a representation or a warranty. It is supplied on the condition that you shall make your own tests to determine the suitability of our product for your particular purpose. Any use or application other than recommended herein is the sole responsibility of the user. Listed physical properties are typical and should not be construed as specifications. NO WARRANTY IS MADE, EXPRESSED OR IMPLIED, REGARDING SUCH OTHER INFORMATION, THE DATA ON WHICH IT IS BASED, OR THE RESULTS YOU WILL OBTAIN FROM ITS USE. N0 WARRANTY IS MADE, EXPRESSED OR IMPLIED, THAT OUR PRODUCT SHALL BE MERCHANTABLE OR THAT OUR PRODUCT SHALL BE FIT FOR ANY PARTICULAR PURPOSE. NO WARRANTY IS MADE THAT THE USE OF SUCH INFORMATION OR OUR PRODUCT WILL NOT INFRINGE UPON ANY PATENT. We shall have no liability for incidental or consequential damages, direct or indirect. Our liability is limited to the net selling price of our product or the replacement of our product, at our option. Acceptance of delivery of our product means that you have accepted the terms of this warranty whether or not purchase orders or other documents state terms that vary from this warranty. No representative is authorized to make any representation or warranty or assume any other liability on our behalf with any sale of our products. Our products contain chemicals that may CAUSE SERIOUS PHYSICAL INJURY. BEFORE USING, READ THE SAFETY DATA SHEET AND FOLLOW THE PRECAUTIONS TO PREVENT BODILY HARM.
