Return to previous page
  • Overview
  • Specs
  • Which Film to Choose
  • How to Measure
  • How to Apply

SP Blue75x Spectrally Selective Exterior Window Film | Rejects 88% Infrared Energy | 76% Visible Light Transmission | Blocks 99% UV | Blue Tint

SP Blue 75X exterior window film delivers excellent levels of heat rejection. Spectrally Selective, it is designed to designed to provide outstanding IR & UV Energy Rejection while still allowing a maximum of visible light to transmit through. The subtle blue tint of this film filters 88% of heat building IR radiation to keep a building cooler and more comfortable without blocking welcome daylight. SP Blue 75X exterior window film is compatible with all glass glazing window systems and is popular in residential and commercial projects.

Available in 25′, 50′, 75′ & 100′ long increments. To save you time cutting film, custom widths cut to order are available.  Please specify the requested width(s) in the “Order Notes” section at the bottom left side of the checkout page.  Can specify up to 3 cuts in width per roll.

WHERE IS EXTERIOR WINDOW FILM USED?

  • Office Buildings
  • Residential Home
  • Commercial Projects
  • Home windows
  • Patio Doors
  • Restaurants
  • Schools
  • Store Fronts
  • Airports
  • Hospitals

WHY EXTERIOR WINDOW FILM?

  • Lower Cooling Costs with Maximum Reduction of Daytime Temperatures
  • Filters 88% of heat-building IR radiation
  • Keeps building comfortable without blocking welcome daylight
  • Blocks 99% of UV Radiation
  • Subtle Blue Tint
  • Easy Application to Exterior Side of Window
  • Available in 25′, 50′, 75′ & 100′ Lengths
  • Custom Widths Available

Specifications

Technical Specs Single Pane Window Double Pane Window
Visible Light Transmitted 76% 69%
Visible Light Reflected (Interior) 9% 17%
Visible Light Reflected (Exterior) 9% 15%
Ultraviolet Block 99% 99%
Total Solar Energy Reflected 8% 10%
Total Solar Energy Transmitted 39% 34%
Total Solar Energy Absorbed 53% 56%
Emissivity (Room Side) 0.84 0.84
Glare Reduction 16% 15%
Selective IR Reduction (SIRR) 88% 88%
IR Energy Reduction (IRER) 63% 63%
Shade Coefficient 0.62 0.50
Solar Heat Gain Coeff. (G-Value) 0.54 0.43
U-ValueWinter (IP) 1.04 0.48
U-Value Winter (SI) 5.91 2.73
Luminous Efficacy 1.20 1.38
Total Solar Energy Rejected (%) 46% 57%

IMPORTANT: If you are unsure what type of glass you have, it is safest to assume that you have ANNEALED glass

Exterior Films Comparison

How to Measure

Determining the amount of window film needed to cover your windows is not as difficult as one would imagine. Just follow these straightforward steps to easily measure your windows and determine the quantity needed.

Measuring Your Glass

Note: Measure width in INCHES and length in FEET (divide number of inches by 12 to convert to feet.)

  1. Measure only glass area of window, not entire window frame.
  2. First measure your glass from left to right in INCHES. This is your required width. (This width corresponds with the “Roll Width” listed on each product page.)
  3. Then Measure your glass from top to bottom in FEET. This will be your required length. (This length corresponds with “Total Length (Feet)” on each product page.)
  4. Be sure to write these measurements down. We suggest adding 1 inch in each direction to your measurements. This allows room for error and cutting during your installation. The slight overlap will allow you to carefully cut the film to the edge of your glass, custom fitting your window.
  5. Repeat measuring for each window.
  6. Add together the lengths for all of your windows to come up with Total Length of film required in FEET.

Ordering Your Window Film

  1. Navigate to the page of the desired film. Select the width in INCHES that best fits your windows as determined by the previous steps.
  2. Your Total Length measurement (length of all windows combined in FEET) equals the quantity needed in feet of your chosen film. Ships as one continuous roll

Below we have listed the General Application Instructions. For additional information, including cleaning & maintenance of your film, please visit our Document Library

NOTE: All Exterior films require edge sealing (including skylights). Instructions are at the bottom of this page.
