R Silver 20i Window Film
R silver Exterior Window FIlm

R Silver 20X Exterior Heat Reflective Window Film | Rejects 81% Infrared Energy | 17% Visible Light Transmission | Blocks 99% UV | Silver Color

Starting at $236.45

  • Lower Cooling Costs with Maximum Reduction of Daytime Temperatures
  • Excellent Solar Energy Rejection of 81%
  • Blocks 99% of UV Radiation
  • Lets 17% of Visible Light Through
  • 81% Glare Reduction
Calculate Square Footage

Overview

  • Description
  • Additional Information
  • Specs
  • Application
  • Calculator

R Silver 20X Exterior Heat Reflective Window Film | Rejects 81% Infrared Energy | 17% Visible Light Transmission | Blocks 99% UV | Silver Color

Avery Dennison’s R Silver 20X Exterior Reflective Window film is designed with commercial projects in mind. While offering an attractive silver appearance, it offers high energy savings rejecting 84% of infrared energy (how most heat is transmitted in the atmosphere) while offering a glare reduction of 81% and only allowing 17% of visible light to transmit through.

The R Silver 20x is an ideal solution solution for an affordable energy-saving project where reducing energy costs and maintaining an attractive look are ideal and there is easy access to the exterior side of window.

The R Silver 20X is an easy wet application to the exterior side of the window.  Please see Application tab for detailed application instructions, our Video tab and Cleaning tab for additional insights.

Available in 25′, 50′, 75′ & 100′ long increments, it also has available widths of 36″, 48″, 60″ & 72″. To save you time cutting film, custom widths cut to order are available. To do so, simply order the next largest width listed (ex: you need a width of 32″, then order 36″ and you will receive a roll cut to 32″ wide and a 2nd piece 4″ wide).  Please specify the requested width(s) in the “Order Notes” section at the bottom left side of the checkout page.  Can specify up to 3 cuts in width per roll.



WHERE IS EXTERIOR REFLECTIVE WINDOW FILM USED?

  • Office Buildings
  • Home windows
  • Patio Doors
  • Restaurants
  • Schools
  • Store Fronts
  • Airports
  • Hospitals

WHY EXTERIOR REFLECTIVE WINDOW FILM?

  • Lower Cooling Costs with Maximum Reduction of Daytime Temperatures
  • Excellent Solar Energy Rejection of 81%
  • Blocks 99% of UV Radiation
  • Lets 17% of Visible Light Through
  • 81% Glare Reduction
  • Easy Application to Exterior Side of Window
  • Available in 25′, 50′, 75′ & 100′ Lengths
  • Available in 36″,48″,60″ & 72″ Widths (Custom Widths Are Also Available)
Weight 20 lbs
Dimensions 72 × 9 × 9 in
Color

Surface Applied To

Manufacturer

Width

36", 48", 60", 72"
Length

25', 50', 75', 100'

Specifications

Technical Specs Single Pane Window Double Pane Window
Visible Light Transmitted 17% 16%
Visible Light Reflected (Interior) 62% 62%
Visible Light Reflected (Exterior) 62% 62%
Ultraviolet Block 99% 99%
Total Solar Energy Reflected 63% 64%
Total Solar Energy Transmitted 12% 11%
Total Solar Energy Absorbed 25% 25%
Emissivity (Room Side) .84 .84
Glare Reduction 81% 80%
Selective IR Reduction (SIRR) 91% 91%
IR Energy Reduction (IRER) 84% 84%
Shade Coefficient .22 .18
Solar Heat Gain Coeff. (G-Value) .19 .15
U-ValueWinter (IP) 1.04 .48
U-Value Winter (SI) 5.51 2.73
Luminous Efficacy .75 .91
Total Solar Energy Rejected (%) 81% 85%

How to Measure

Determining the amount of window film needed to cover your windows is not as difficult as one would imagine. Just follow these straightforward steps to easily measure your windows and determine the quantity needed.

Measuring Your Glass

Note: Measure width in INCHES and length in FEET (divide number of inches by 12 to convert to feet.)

  1. Measure only glass area of window, not entire window frame.
  2. First measure your glass from left to right in INCHES. This is your required width. (This width corresponds with the “Roll Width” listed on each product page.)
  3. Then Measure your glass from top to bottom in FEET. This will be your required length. (This length corresponds with “Total Length (Feet)” on each product page.)
  4. Be sure to write these measurements down. We suggest adding 1 inch in each direction to your measurements. This allows room for error and cutting during your installation. The slight overlap will allow you to carefully cut the film to the edge of your glass, custom fitting your window.
  5. Repeat measuring for each window.
  6. Add together the lengths for all of your windows to come up with Total Length of film required in FEET.

Ordering Your Window Film

  1. Navigate to the page of the desired film. Select the width in INCHES that best fits your windows as determined by the previous steps.
  2. Your Total Length measurement (length of all windows combined in FEET) equals the quantity needed in feet of your chosen film. Ships as one continuous roll

How to Apply

Below we have listed the General Application Instructions. For additional information, including cleaning & maintenance of your film, please visit our Document Library

NOTE: All Exterior films require edge sealing (including skylights). Instructions are at the bottom of this page.

Fullscreen Mode

Square Footage Calculator

Estimate the Right Amount for Your Project

Use the calculator to determine your total project square footage. Once you have your measurements, compare the result to the product coverage rate listed on this page to estimate how much material you'll need for complete coverage.

Calculate Coverage
Quickly determine the total square footage of your project area.

Estimate Product Quantity
Use your results to calculate how much product your project requires.

Plan With Confidence
Add a waste percentage to account for surface texture and application conditions.

Coverage estimates are provided as a general guide. Actual product usage may vary based on surface condition, porosity, application method, and project requirements.

Square Feet 0 ft²
