MIXING AND APPLICATION INSTRUCTIONS
SUBSTRATE PREPARATION: The most suitable surface preparation would be a fine brush blast (shot blast) to remove all laitance and provide a suitable profile. All dirt, foreign contaminants, oil and laitance must be removed to assure a trouble free bond to the substrate. A test should be made to determine that the concrete moisture content is controlled to acceptable levels, this can be done by placing a 4’X4’ plastic sheet on the substrate and taping down the edges. If after 24 hours, the substrate is still dry below the plastic sheet, then the substrate is generally considered suitable for coatings. The plastic sheet testing is also a good method to determine if any hydrostatic pressure problems exist that may later cause disbonding. After surface preparation and before application, repair all bug holes and grind down any projections. Repair all cracks or concrete Imperfections. Surface should have a minimum tensile strength of at least 300 psi @ ASTM D-4541. Surface profile should be CSP 3-5 per International Concrete Repair Institute guidelines.
PRODUCT STORAGE: Store product in an area as to bring the material to normal room temperature before using. Continuous storage should be between 60 and 90 degrees F. Low temperatures may cause product crystallization. Do Not Freeze.
PRODUCT MIXING: This product is packaged in pre-measured kits. Use the entire kit – do not modify. Pour the part A into a five gallon mixing vessel. If adding color, add one bag of the powder pigment to the part A and mix about 15 seconds using a 1/2″ drill and jiffy type mixing paddle. Next, add the part B and again mix for about 15 seconds. Finally, gradually add all of the contents from the provided aggregate filler bag into the liquid mixture and blend thoroughly until all particles are thoroughly wetted out; this will usually take about two minutes. Use slow speed mixing equipment to avoid adding air into the mix. After mixing, transfer the mixed material to another pail (the transfer pail) and again remix. The material in the transfer pail is now ready to be applied on the prepared substrate. Remix occasionally to prevent settling of aggregate. Improper mixing may result in product failure. Make sure to apply the product immediately after it is completely mixed
For best mixing results and proper blending of parts A and B, recommend a JIFFY MIXER style drill mixer.
Use of an improper drill mixer can result in streaking of the color because the pigment has not been thoroughly blended. It can also create curing problems if the hardener also called activator (Part B) is not thoroughly blended with the resin (Part A) which can cause some areas on your floor to remain soft and not harden properly. DO NOT USE A PAINT MIXER. Many mixing problems described above can be traced back to using a paint mixer.. DO NOT HAND MIX as this approach can also result in the same problems as using a paint mixer.
Product Application: Have the floor as dry as possible without any puddles of water present. To prevent lifting and delaminations, keyways (minimum 5/16″ wide x 5/16″ deep) must be cut at all terminations, joints, columns, doorways and drains. Immediately after mixing, spread the mixed material onto the floor at the desired thickness, using a GUAGE/CAM RAKE or other suitable equipment; approximately 1/8″ for a 3/16: finished floor. Apply abutting edges within 5-10 minutes to ensure a clean edge. A “wet edge” installation is imperative for larger areas to avoid lines and ridges in the finished floor. When installing, evenly apply to the desired thickness while trying to keep the cam rake lines to a minimum.
Backroll across the applied slurry with a SPIKE ROLLER roller to help settle aggregate and blend in cam rake lines.
Further roll with a LOOP/TEXTURE ROLLER perpendicular to cam rake lines over the entire floor surface to even and settle the slurry prior to broadcasting. Finally, broadcast to rejection with the desired broadcast media (aggregate or decorative flakes) onto the wet slurry.
Do not broadcast onto the wet edges until settling and backrolling is complete. Continue to broadcast until no wet areas remain. After Curing (typically around 6-8 hours for light foot traffic), remove all excess broadcast media and scrape floor as desired. A topcoat can now be applied to lock in the aggregate. Surfaces not broadcasted could have an uneven texture, color streaks or color differences and an orange peel look. Maintain temperatures and relative humidity within the recommended ranges during the application and curing process. Do not apply to cracked or unsound concrete. Do not feather edge
For best thermal shock and heat resistance and achieve a 3/16” broadcast system, broadcast 20-40 mesh silica sand into the floor. Do not broadcast the silica directly into the floor, but broadcast it upward, in a fanning motion, until complete rejection (full broadcast to refusal). It is very important to make sure the silica is broadcasted as even as possible. When adding silica sand, will then need to add the E903TC Urethane topcoat to fully encapsulate and cover the silica. Once the floor is cured, about 6 hours later, sweep the floor for any excess aggregate, this silica can be reused.
Topcoat: The E903TC Urethane topcoat is required to encapsulate the silica if it is broadcast into the E903SL. If silica aggregate is not broadcasted into the E903SL slurry system, then a top coat is optional but strongly recommended for optimum floor system performance. In some areas, a suitable novolac or other types of coatings can be used, depending on specific requirements.
Cleanup For cleaning any application, equipment, water can be used. The urethane component container is best cleaned with a suitable solvent.
Floor Cleaning and Restrictions: Caution! Some cleaners may affect the color of the floor installed. Test each cleaner in a small area, utilizing your cleaning technique. If no ill effects are noted, you can continue to clean with the product and process tested. Restrict the use of the floor to light traffic and non-harsh chemicals until the coating is fully cured (see technical data under full cure). It is best to let the floor remain dry for the full cure cycle. Dependent on actual complete system application, surface may be slippery, especially when wet or contaminated; keep surface clean and dry.
LIMITATIONS
- Color stability or gloss may be affected by high humidity, low temperature, chemical exposure or lighting such as sodium vapor lights.
- Product is not color or UV stable.
- Do not install on wet concrete.
- Floors should be sloped to drain to prevent standing water or chemicals and spills should be removed as soon as possible to prevent a slipping hazard.
- Proper mixing is important for product performance.
- High heat exposure may discolor the surface.
- Colors may vary from batch to batch. Therefore, use only product from the same batches for an entire job.
- Always apply a suitable test area to evaluate the product performance and suitability prior to undertaking the entire project. Samples are available upon request.
- Mixtures of chemicals and applications with exposures to chemicals at elevated temperatures should be thoroughly evaluated before applying.
- Substrate temperature must be 5°F above dew point.
- All new concrete must be cured for at least 15 days prior to application.
- Moisture vapor transmission should be less than 12 pounds or less per 1,000 sq. ft. over a 24 hour period as per ASTM E1907.
