E811FP Acrylic Roof Coating

SPECIFICATIONS	UNDERWRITERS LABORATORIES, INC., TESTED AND CERTIFIED U.L. CERTIFICATION TESTING DATA AVAILABLE UPON REQUEST
Solids (weight)	65%
Solids (volume)	63%
Colors	6 colors
Recommended Film Thickness	20-22 mils wet per coat x 2 coats = 40-45 mils wet total (25-30 mils dry film thickness)
Coverage Rate	Depends on surface conditions and application conditions, normally 1.5 gallon per 100 sq’ per coat x 2 coats.  Coverage for 2 coats combined 33-34 sq’/gallon
Packaging	5 gallons, 53 gallon drum
Shelf Life	12 months in unopened container at 65°F
VOC
Flash point	212°F  (no flash) ASTM D3278 seta flash closed cup apparatus
Heat stability	10 days at 120°F then re-evaluated:  Material stability maintained
Particle Size	<38 microns or hegman 4-5  ASTM 1218
Density	Mean=10.54#/gallon    ASTM D1475 U.S. standard weight per gallon cup at 75°F and 50% R.H
Viscosity @77°F, 50% R.H	101 kreb units ASTM D115 Thomas Stormer Model 9730-G45
Hardness	50-60  ASTM D2240 shore A @75°F 50% R.H. Barcol hardness tester model 3061
Accelerated Weathering	Excellent with no apparent degradation      ASTM G53 (9000 hours QUV accelerated weather tester UV-B lamps no. QES-40/280-315 nanometers. (12 hr. QUV @ 60°C and 12 hr. con @ 50°C)
Tensile Strength	318 psi  ASTM D412 @ 75°F and 50% R.H. Test is result of medium value(for 3)
Elongation	415% minimum    ASTM D412 @ 75°F and 50% R.H
Permeance	7 perms ASTM D1653A
Thermal Emittance	0.87
Solar Reflectance	81.2 (white) ASTM E903
ASTM D-6083 Meets or Exceeds (STANDARD SPECIFICATION FOR LIQUID APPLIED ACRYLIC COATING USED IN ROOFING)	including ASTM D562, ASTM D2196, ASTM D2697, ASTM D1644, ASTM D2370, ASTM D1653A, ASTM D471, ASTMD4798, ASTM C794, ASTM D903, ASTM G21, ASTM D624, ASTM D522  UNDERWRITERS LABORATORIES INC. TESTED &  CERTIFIED

MIXING AND APPLICATION INSTRUCTIONS

PRODUCT STORAGE: Store product in an area so as to bring the material to normal room temperature before using. Continuous storage should be between 60 and 80 degree F.  Keep from freezing.

SURFACE PREPARATION: Make certain that the substrate where the product is to be applied is clean, sound and free of all laitance, dirt, dust, oil, grease, or foreign contaminants. Wire brush or abrasive blast all loose and scaling rust from the roof. Apply E815 to all head laps and boltheads.

ENVIRONMENTAL CONDITIONS: Make certain that the roof temperature and the air temperature as well as any humidity recommendations are within the recommended ranges before applying the product.  Recommend applications with temperatures above 50F and Relative humidity below 95% with no rain imminent within 24 hours.

APPLICATION:  This product may be applied by roller, brush, or spray. Be sure to apply this product at the specified coverage rate or recommended mil thickness. We recommend a Graco 520 with 729 tip or other suitable spray equipment with a coverage rate of 1 1/2 gallons per 100 square feet per coat (two coats recommended) Allow sufficient time between coats, and remember, as temperatures become lower this product will require additional time to cure. Always check the previous coat for foreign contamination before recoating. Clean or prepare the preceding coat if an inspection so warrants before applying any additional coats.  Take notice of the full cure time and do not open the area to abusive use before the full characteristics of the coating is achieved.

For best mixing results and proper blending  recommend a Jiffy Mixer style drill mixer.

REOPEN SERVICE TIME:  Take notice of the full cure time and do not open the area to abusive use before the full characteristics of the coating is achieved.

MAINTENANCE: Provide for routine maintenance of your roof to assure years of trouble free performance.

LIMITATIONS

• Allow material to cure (24 hours) before exposure to rain or dew.
• Do not apply a second coat until the first coat is dry.
• Do not apply thicker than recommended.
• Read the SDS before using this product.
• Product is not resistant to solvent exposure.
• Physical properties are typical values and not specifications.
