E5521 High Gloss Aliphatic High Performance Urethane | Low Odor | Vapor Permeable

E5521 is a two component High Gloss aliphatic polyurethane coating that exhibits excellent characteristics for impact and abrasion resistance, chemical resistance, flexibility, weathering, and UV stability.  Easy to work with for a wide range of indoor commercial, industrial and residential concrete floor projects.

Great for use where a low odor, vapor permeable water based topcoat is required.

Available in a high gloss clear.  For even greater abrasion wear resistance consider using the High Wear 325 aluminum oxide additive.  Available for air shipment.  Comes in quart, 3/4 gallon, 1.5 gallon, 3 gallon and 15 gallon kits.  Not for use direct to concrete.

PRIMER: Recommend the E5015 water based epoxy or E707LVP Epoxy primers.

TOPCOAT: None recommended

E5521 High Gloss Aliphatic Urethane Used?

  • Garages
  • Auto Service Centers
  • Warehouses
  • Computer Rooms
  • Laboratories
  • Aircraft Hangers
  • Cafeterias
  • Chemical Exposure Areas
  • Indoor projects

Why E5521 High Gloss Aliphatic Urethane?

  • Outstanding durability with impact resistance of 120 in lb (Gardner Impact test)
  • Excellent abrasion resistance Only 21 mg loss (Tabor Abrasion test) Reduced to as low as 10 mg loss using our High Wear 325 additive
  • Excellent Chemical Resistance
  • Aliphatic, UV Stable and will not yellow
  • Great for Indoor Concrete Floor Projects
  • Low odor, water based formula
  • Vapor Permeable Topcoat

SPECIFICATIONS

Solids (weight) 42%
Solids (volume) 38%
VOC  305 g/l
Colors  Clear only
Recommended Film Thickness  3-5 mils wet (do not apply thicker)
Coverage per Gallon  320 – 500 sq’/gal @3-5 mils wet thickness
Packaging quart, 3/4 gallon, 1.5 gallon kit, 3 gallon kit, and 15 gallon kit
Mix Ratio 2:1 mix ratio by volume
Shelf Life 6 months in unopened container
Finish  Low gloss (>700 at 60 degrees @glossmeter)
Abrasion Resistance Tabor abrasor CS-17 wwheel with 1000 gram total load and 500 cycles = 23.0  mg loss  (As low as 10 mg loss when used with High Wear 325 additive)
Impact Resistance Gardner impact, direct = 160 in. lb (passed)
Flexibility  No cracks on a 1/8″ mandre
Adhesion >300 psi @ecometer (concrete failure, no delamination)
Viscosity  Mixed = 500 – 1000 cps (typical)
 DOT Classification Part A “Not Regulated, Part B “Not Regulated”

COVERAGE RATE

Coverage Per Gallon  320 – 500 Sq’/Gal @3-5 Mils Wet Thickness

CURE SCHEDULE

Pot Life – 150 gram mass Minimum 1 hour
Tack Life (dry to touch) 7-9 hours
Recoat or Topcoat 8-12 hours
Light foot traffic 24 hours
Full cure (heavy traffic) 3 – 5   days

APPLICATION TEMPERATURE: 60-90 degrees F with relative humidity between 50% and 90%

CHEMICAL RESISTANCE

RATING
 acetic acid 5% C
 xylene D
 mek B
 methyl alcohol B
 gasoline D
 10% sodium hydroxide E
 50% sodium hydroxide D
 10% sulfuric D
 10% hydrochrolic acid D
 20% nitric acid C
ethylene gylycol D

Rating key: A – not recommended, B – 2 hour term splash spill, C – 8 hour term splash spill, D – 72 hour immersion, E – long term immersion.

MIXING AND APPLICATION INSTRUCTIONS

PRODUCT STORAGE: Store product in an area so as to bring the material to normal room temperature before using. Continuous storage should be between 60 and 90 degree F. Keep from freezing.

SURFACE PREPARATION: Surface preparation will vary according to the type of complete system to be applied.  For a one or two coat thin build system (3-10 mils dry) we recommend either mechanical scarification or acid etching until a suitable profile is achieved.  For a complete system build higher than 10 mils dry, we recommend a fine brush blast (shot blast).  All dirt, oil, dust, foreign contaminants and laitance must be removed to assure a trouble free bond to the substrate. A test should be made to determine that the concrete is dry; this can be done by placing a 4’X4’ plastic sheet on the substrate and taping down the edges.  If after 24 hours, the substrate is still dry below the plastic sheet, then the substrate is dry enough to start coating.  The plastic sheet testing is also a good method to determine if any hydrostatic pressure problems exist that may later cause disbonding.)

PRODUCT MIXING:This product has a two to one mix ratio by volume- as an example for a 3 gallon kit, merely mix two gallons of part A with 1 gallon part B.  After the two parts are combined, mix well with slow speed mixing equipment such as a jiffy mixer until the material is thoroughly mixed and streak free.  Avoid whipping air into the coating.

Improper mixing may result in product failure. For best mixing results and proper blending of parts A and B, recommend a Jiffy Mixer style drill mixer.

Use of an improper drill mixer can result in curing problems if the hardener also called activator (Part B) is not thoroughly blended with the resin (Part A) which can cause some areas on your floor to remain soft and not harden properly.  DO NOT USE A PAINT MIXER.  Most mixing problems described above can be traced back to using a paint mixer..  DO NOT HAND MIX as this approach can result in the same problems as using a paint mixer.

PRODUCT APPLICATION: The mixed material can be applied by brush or 3/8″ nap lint free roller.  Maintain temperatures within the recommended ranges during the application and curing process.  Properly prime the substrate.  It is best to maintain a wet edge to avoid roller marks.  Direct sunlight or high temperatures may cause visible roller marking during application.

Uneven application thicknesses may cause variations in gloss, therefore apply material as evenly in thickness as possible.  Too thick of an application may result in solvent entrapment and product failure. Although the pot life may appear to be longer, do not apply after one hour after the two components have been mixed. Once mixed, air exposure might cause a slight skimming on the surface in the roller pan or container if left uncovered, even for a few minutes. If skimming occurs, remove the thin layer, then stir and continue to use the product for up to an hour after it has been mixed. Material left unused in the mixing pail or application tray may expand and foam up after an extended period of time. 5)

RECOAT OR TOPCOATING: Multiple coats of this product are acceptable.  If you opt to recoat this product, you must first be sure that all of the volatile components have evaporated from the coating during the curing process.  The information on the front side are reliable guidelines to follow.  However, it is best to test the coating before recoating or topcoating.  This can be done by pressing on the coating with your thumb to verify that no fingerprint impression is left.  If no impression is created, then the recoat can be started.

Always remember that colder temperatures will require more cure time for the product before recoating can commence. Before recoating or topcoating, check the coating to insure no contaminants exist.  If a blush or contaminants are present on a previous coat, remove with a standard type detergent cleaner and allow to completely dry.  When recoating this product with subsequent coats of the urethane, it is advisable to apply the recoat before 24 hours passes.  Also, it is advisable to degloss the previous coat to insure a trouble free bond.

CLEANUP: Use soap and water or a water soluble solvent before the coating dries.

SURFACE CLEANING: Caution! Some cleaners may affect the color of the floor installed. Test each cleaner in a small area, utilizing your cleaning technique. If no ill effects are noted, you can continue to clean with the product and process tested.

RESTRICTIONS: Restrict the use of the surface to light duty and non-harsh chemicals until the coating is fully cured (see technical data under full cure). It is best to let the surface remain dry for the full cure cycle. Dependent on actual complete system application, surface may be slippery, especially when wet or contaminated; keep surface clean and dry.

LIMITATIONS

  • After the product is mixed, air contact may cause the material to skim off if left uncovered. See reverse under application instructions.
  • Colors or gloss may be affected by high humidity, low temperatures, or chemical exposure.
  • For best results use a high quality 3/8”nap roller.
  • Slab on grade requires moisture barrier.
  • Substrate temperature must be 5°F above dew point.
  • All new concrete must be cured for at least 30 days.
  • Physical properties are typical values and not specifications.
  • Tire contact may cause staining and discoloration.
  • Slight appearances in gloss may vary from batch to batch, therefore, use only product from same batch for an entire job.
  • Lights like sodium vapor lights can cause discoloring.
  • Physical properties are typical values and not specifications.

NOTICE TO BUYER: DISCLAIMER OF WARRANTIES AND LIMITATIONS ON OUR LIABILITY We warrant that our products are manufactured to strict quality assurance specifications and that the information supplied by us is accurate to the best of our knowledge. Such information supplied about our products is not a representation or a warranty. It is supplied on the condition that you shall make your own tests to determine the suitability of our product for your particular purpose. Any use or application other than recommended herein is the sole responsibility of the user. Listed physical properties are typical and should not be construed as specifications. NO WARRANTY IS MADE, EXPRESSED OR IMPLIED, REGARDING SUCH OTHER INFORMATION, THE DATA ON WHICH IT IS BASED, OR THE RESULTS YOU WILL OBTAIN FROM ITS USE. N0 WARRANTY IS MADE, EXPRESSED OR IMPLIED, THAT OUR PRODUCT SHALL BE MERCHANTABLE OR THAT OUR PRODUCT SHALL BE FIT FOR ANY PARTICULAR PURPOSE. NO WARRANTY IS MADE THAT THE USE OF SUCH INFORMATION OR OUR PRODUCT WILL NOT INFRINGE UPON ANY PATENT. We shall have no liability for incidental or consequential damages, direct or indirect. Our liability is limited to the net selling price of our product or the replacement of our product, at our option. Acceptance of delivery of our product means that you have accepted the terms of this warranty whether or not purchase orders or other documents state terms that vary from this warranty. No representative is authorized to make any representation or warranty or assume any other liability on our behalf with any sale of our products. Our products contain chemicals that may CAUSE SERIOUS PHYSICAL INJURY. BEFORE USING, READ THE MATERIAL SAFETY DATA SHEET AND FOLLOW ALL PRECAUTIONS TO PREVENT BODILY HARM.
